Pinbraid: Harness Builder

About Pinbraid: Harness Builder

Pinbraid is a private cable-assembly desk for prototype teams, electronics labs, robotics builders, repair benches, vehicle projects, and low-volume harness work.

Define connectors and viewing orientation, map every net from pin to pin, record conductor gauge, color, cut length, and measured resistance, and catch duplicate endpoints or out-of-range pins before assembly. A cut board estimates copper loop drop from entered length, gauge, and current, while the continuity matrix keeps pass, open, short, and untested evidence attached to the released map.

KEY FEATURES
- Connector and pin-range definitions
- Endpoint collision and range validation
- Net names, colors, gauges, and cut lengths
- Continuity state and measured resistance
- Copper loop-resistance and voltage-drop screen
- Assembly gate checklist
- Local harness packet PDF
- 300 original offline technical plates
- No account, ads, analytics, tracking, IAP, or subscription

Pinbraid documents intended cable assemblies and low-energy continuity results. Confirm connector orientation, pin numbering, conductor ratings, insulation, shielding, test limits, and equipment procedures at the bench.
